Crown 4-Channel Power Amplifier, 1200W per channel, powerful performance for large installations with advanced DSP and full network control. CDi 4|1200
- The Crown CDi 4|1200amplifiers come to offer one of the most powerful professional amplification solutions in its class, giving you four independent channels with 1200 watts of power per channel, making it an ideal choice for large projects such as cinemas, grand mosques, hotels, theaters, cruise ships, and huge shopping malls.
- Power Amplifier Fire device Based on the advanced DriveCore platform, which offers high efficiency, low power consumption, and excellent stability during long-term operation.
- The device also features a built-in DSP for complete control of audio processing, with support for direct 70V/100V operation without external adapters, as well as preset JBL settings to facilitate adjustment and installation.
Technical description:
- The CDi 4|1200 amplifiers combine massive power and technical precision via an advanced DSP that includes EQ, crossover filters, delay, and Limiter LevelMAX to ensure protected and clean sound no matter the load.
- Network control via HiQnet Audio Architect gives you the ability to adjust, monitor, and manage four channels independently, making it suitable for distributing sound in multiple areas without the need for additional amplifiers.
- The device is designed to handle high loads smoothly, and delivers a precise and stable frequency response without any audible distortion.
Technical specifications:
- Number of channels: 4
- Output power per channel (4Ω): 1200W
- Sensitivity: 0.7V RMS
- Signal-to-noise ratio: >104dB
- Total distortion (THD): 0.35%
- Damping factor: >1000
- Frequency response: ±0.25dB (20Hz – 20kHz @ 8Ω)
- Channel separation: >80dB
- Input impedance:
- 20kΩ balanced
- 10kΩ unbalanced
- Dimensions: 19 x 3.5 x 14.71 inches
- Weight: 9.12 kg
- Power supply: 100–240V
- Internal DSP: Yes
- BLU link: Not supported
- Power connector: 20A IEC
Key features:
- Four powerful channels with a power of 1200 watts per channel.
- DSP is comprehensive for high-precision audio processing and signal adjustment.
- DriveCore technology to increase reliability and reduce power consumption.
- Supports 70V/100V systems directly without transformers.
- A complete control network via HiQnet Audio Architect.
- JBL settings are ready for quick adjustments and professional results.
- Excellent separation between channels prevents interference and gives clearer sound.
- Durable design suitable for long-term intensive use.
Product summary:
- The Power Amplifier Fire device The Crown CDi 4|1200 is one of the most powerful amplifiers in its class, delivering consistent, high-powered performance with a professional DSP that makes it suitable for any project requiring high sound power and multi-zone distribution.
- Whether you are working on equipping a large mosque, cinema, theater, or commercial facility, this amplifier gives you the power, flexibility, and reliability you need to run a complete sound system at the highest quality.
Additional features:
Input delay of up to 1000ms for synchronization operations.
Eight-band EQ input and output for professional location frequency adjustment.
LevelMAX protection ensures clear sound and prevents damage to the speakers.
Front-end interface for quick and direct manual control.
Supports GPIO/AUX control for integration with external control systems.
Applications used for the product:
1. Large mosques
It provides an even distribution of sound across four channels, with DSP allowing for clarity adjustment and feedback reduction, making it ideal for Friday sermons and the call to prayer.
2. Cinemas and theaters
It offers massive power with precise processing suitable for cinematic scenes and 3D sound effects.
3. Schools and universities
Suitable for a sound system that covers multiple halls over the same device using 4 independent channels.
4. Hotels and malls
It supports the distribution of background music and audio advertisements with ease and high flexibility.
5. Cruise ships and large facilities
Its high power makes it ideal for complex audio systems with long distances and changing environments.
Summary and final advice:
- If you need a powerful multi-channel amplifier that delivers tremendous power, professional audio processing, and unparalleled reliability, the CDi 4|1200 is the perfect choice for your project.
- The device is designed for large, error-free projects, and provides you with the flexibility to distribute and monitor sound in a professional and convenient manner.
Detailed product data (Data Sheet).
