Line Array 1560W 3-way speaker system with a 60° coverage angle for superior professional performance in large spaces. Model VLA601i
- It is considered a theater amplifier The JBL VLA601i is a professional audio system designed to deliver strong and balanced performance in large projects that require high-quality sound clarity over long distances.
- The speaker belongs to JBL’s renowned Variable Line Array (VLA Series), which has redefined long-range sound distribution technologies thanks to its precise acoustic engineering and advanced components.
- The VLA601i large speakers are designed to provide balanced, horizontally directed sound at a 60-degree angle, giving you focused and ideal sound coverage in wide environments.
- The speaker combines two low-frequency speakers (15 inches), two mid-frequency speakers (8 inches), and three high-frequency compression drivers (1.5 inches) to deliver an exceptional audio experience characterized by power, clarity, and precision in detail.
Technical description:
- The JBL VLA601i theater amplifier is specifically designed for fixed-mount applications in projects that require powerful, precisely directed sound.
- The speaker features a 3-Way Full Range Line Array design, making it capable of handling a wide range of frequencies with a perfect balance between low, mid, and high frequencies.
- The speaker provides a total operating power of up to 1560 watts (AES) with a maximum sound pressure of up to 147.2 dB SPL, making it ideal for stadiums, arenas, and large theaters.
- It also features the renowned JBL Differential Drive® technology, which delivers stronger performance with less weight and reduces distortion, as well as a weather-resistant DuraFlex™ coating to ensure stability and durability in all environmental conditions.
Technical specifications:
- Type: Line Array 3-Way (3-Way Full Range) Headset
- Electrical power (AES):
- LF: 1000W Continuous
- MF: 400W Continuous
- HF: 160W Continuous
- Total power: 1560 watts
- Frequency range (-10 dB): 41 Hz – 20 kHz
- Frequency response (-6 dB): 45 Hz – 19.5 kHz
- Frequency response (-3 dB): 50 Hz – 19.2 kHz
- Horizontal coverage angle: 60° (from 500 Hz to 16 kHz)
- Vertical coverage angle: varies depending on the number of units in the system.
- Maximum sound pressure level (SPL): 147.2 dB (Preset: Flat)
- Sensitivity (2.83 V at 1 m):
- LF: 99/96 dB
- MF: 107/104 dB
- HF: 108/111 dB
- Nominal impedance: 4 ohms
- LF amplifiers:
- (2) × JBL 2265H – 15-inch – Dual 3-inch Coil – Neodymium Differential Drive®
- MF amplifiers:
- (2) × JBL 2169H – 8-inch – Dual 3-inch Coil – Neodymium Differential Drive®
- HF amplifiers:
- (3) × JBL 2432H – 1.5-inch output – 3-inch voice coil – neodymium magnet
- Material: High-quality Finnish birch wood (18mm and 16mm) – DuraFlex™ scratch and moisture resistant coating
- Environmental options:
- WRC: For moisture protection in partially enclosed locations
- WRX: For complete protection in coastal or harsh environments
- Front grille: Zinc-plated perforated steel – Waterproof transparent acoustic foam
- Inputs: Barrier Strip with protective cover and leak-proof clip
- Operating environment: MIL-STD 810 | IPx3 splash and water resistant
- Dimensions (height x width x depth):
- 528 × 1346 × 767 mm (20.8 × 53 × 30.2 inches)
- Net weight: 100.7 kg (222 lbs)
Key features:
- A powerful and professional three-way system for balanced and clear audio coverage across all frequencies.
- High operating power of up to 1560 watts with a sound pressure of up to 147 decibels.
- 60° horizontal coverage angle for concentrated sound distribution in large spaces.
- Differential Drive® technology to reduce weight and improve efficiency.
- DuraFlex™ weather-resistant coating for consistent performance even in harsh conditions.
- An integrated suspension system with high flexibility to facilitate installation and angle adjustment.
- Robust engineering design and high-quality birch wood construction to ensure durability and longevity.
Product summary:
- The JBL VLA601i large speakers combine superior power and high-fidelity sound in one compact and durable design.
- It was specifically designed to meet the needs of large-scale audio projects that require focused and perfectly directed sound.
- Whether in stadiums, outdoor theaters, or grand halls, the speaker gives you an exceptional audio experience that combines power, balance, and clarity in every detail.
Additional features:
- Compatible with other VLA Series systems to form integrated Line Array systems.
- Multiple color and finish options to suit the site's architectural design.
- A robust multi-point suspension system for flexible and secure mounting.
- Front grilles that are resistant to rust and moisture.
- Full integration with Crown DCi DSP amplifiers for intelligent control and efficient power distribution.
Applications used for the product:
- Sports stadiums and major government facilities.
- Outdoor theaters and large-scale events.
- Recreational and cultural centers.
- Major universities and educational institutions.
- Sound systems in public halls and open spaces.
Summary and final advice:
- If you are looking for a professional 1560W Line Array theater speaker with precise 60° sound coverage for your stationary or open-space applications, the JBL VLA601i is the perfect solution.
- Thanks to its robust design, balanced performance and advanced technologies, the headset gives you a powerful, clear and stable sound that meets the highest demands of professional projects.
Detailed product data (Data Sheet).
