VIO S115: Active Wall-Mounted Subwoofer with 15" Woofer
Description of large db headphones
The VIO S115 is a bass reflex active subwoofer with a single 15" woofer. Inspired by dBTechnologies' popular VIO S118R, the VIO S115 offers the same power and flexibility, but can be hung in a variety of acoustic arrangements. With its compact size, this large speaker is one of VIO's most compact subwoofers, ideal as an addition to the full-range VIO X range.
The VIO S115 comes with a 15-inch neodymium woofer powered by a 900W RMS power amplifier, powered by Digipro® G3 technology, making it fully compatible with the rest of the VIO family of speakers. The device’s chassis features M10 and M20 mounting points, allowing it to be used in landscape or portrait mode when hanging or stacked on the floor.
Technical Specifications
- Speaker Type: Active subwoofer with bass reflex technology
- Frequency:
- Frequency Response [-6dB]: 40Hz (with custom frequency adjustment)
- Frequency Response [-10dB]: 36Hz (with custom frequency adjustment)
- Maximum sound pressure (SPL): 134 dB
- Low frequency speaker: 1×15 inch
- Voice coil (LF): 4 inch
- Voice guidance: Omnidirectional
- Amplifier Technology: Digipro® G3
- Amplifier Class: D
- RMS Power: 900W
- Peak power: 1800W
- Cooling system: Convection cooling
Control and processing specifications
- Processor: 32-bit DSP
- AD/DA converter: 24bit/96kHz
- Limiter: RMS, peak, and temperature limit
- Inputs:
- 1 balanced XLR input
- 1 RJ45 (RDNet) port
- Outputs:
- 1 balanced XLR output
- 1 RJ45 (RDNet) port
- Power socket:
- 1 PowerCON input TRUE1
- 1 PowerCON TRUE1 output
- Control:
- 1 sensitivity adjustment knob
- 1 X-Over Selector Knob
- 1 knob for delay selection
- 1 switch for polarity selection
- 1 key to select X-Out mode
- LEDs: On, Status, Signal, Limit, RDNet
Design and Mechanics
- Frame: Made of Multiplex coated polyurethane wood
- Installation: M10 points (16 pieces)
- Mounting Base: 1x M20 top, 1x M20 right side
- Handles: 1 aluminum side handle
- Dimensions:
- Width: 650mm (25.6in)
- Height: 420mm (16.5in)
- Depth: 550mm (21.7in)
- Weight: 32.8 kg (72.3 lbs)
Additional features
- Installation Flexibility: The VIO S115 supports installation in multiple positions (horizontal or vertical), providing multiple configuration options.
- Smart Control Technology: Allows full compatibility with RDNet network control system.
Product Summary
The VIO S115 subwoofer is a compact and flexible device designed to deliver powerful, professional audio performance. With its fly-mount capability and advanced technical features, it is the ideal choice for seamless integration into the VIO family of professional audio systems.
Applications used for the product
- Hanging in large spaces: Ideal for use in large concerts or public events.
- Integration with other audio systems: Works seamlessly with VIO family speakers to achieve optimal sound distribution.
Conclusion and advice
If you are looking for a compact and powerful amplifier with the ability to be installed in multiple setups, the VIO S115 is the perfect solution. This amplifier delivers powerful performance with flexibility in installation and connectivity, making it suitable for large theaters and large events.
